Understanding Modbus Addressing and Frame Structure

A practical guide to decoding Modbus RTU and TCP frames, with tips for troubleshooting field deployments.

Understanding Modbus Addressing and Frame Structure

Whether you’re integrating legacy equipment or building a new IIoT gateway, mastering Modbus framing saves hours of troubleshooting. This guide breaks down the addressing model and how RTU/TCP frames are assembled in real projects.

1. Logical vs. Physical Addressing

Modbus addresses are zero-based, but many vendor manuals use one-based notation. Always confirm:

  • 40001 (manual) equals holding register address 0 in code.
  • Coils (0xxxx), discrete inputs (1xxxx), input registers (3xxxx), holding registers (4xxxx).
  • Unit identifiers matter on gateways bridging multiple devices.

2. RTU Frame Anatomy

| Address | Function | Data ... | CRC |
  1 byte    1 byte   N bytes   2 bytes

Example: Reading two holding registers from slave 0x11

Request: 11 03 00 6B 00 02 CRC
Response: 11 03 04 02 2B 00 00 CRC

Tips:

  • Ensure silent intervals of 3.5 character times between frames.
  • Match baud rate, parity, and stop bits across all nodes.
  • Watch for CRC mismatches caused by noise; add shielding and proper grounding.

3. TCP Frame Anatomy

Modbus TCP wraps PDU data in an MBAP header:

| Transaction ID | Protocol ID | Length | Unit ID | Function | Data |
      2 bytes         2 bytes     2 bytes   1 byte    1 byte    N bytes
  • Transaction ID helps match responses in asynchronous clients.
  • Protocol ID is always 0x0000.
  • Length covers Unit ID + Function + Data.

4. Mapping Devices to Addresses

Create a register map spreadsheet that includes:

TagTypeAddressScalingUnitsNotes
Oven_TempHolding Register40010÷10°CPLC word
Valve_CMDCoil00005BOOLWrite only

Keep the map version-controlled and share it with OT/IT teams.

5. Troubleshooting Workflow

  1. Verify wiring and termination resistors (120 Ω) on RS-485 networks.
  2. Use a protocol analyzer (Modbus Poll, QModMaster, Wireshark) to inspect frames.
  3. Check diagnostics: Many PLCs expose Modbus error counters (timeout, CRC, exception).
  4. Review exception codes (e.g., 0x02 illegal data address) to adjust queries.

6. Sample Python Decoder

from pymodbus.client import ModbusSerialClient

client = ModbusSerialClient(method="rtu", port="/dev/ttyUSB0", baudrate=9600)
result = client.read_holding_registers(address=0, count=2, unit=17)
if result.isError():
    print(result)
else:
    print(result.registers)

7. Best Practices for Field Deployments

  • Group contiguous registers to reduce roundtrips.
  • Avoid mixing slow and fast devices on the same RTU segment; use repeaters if necessary.
  • Document and test fallback strategies when a device goes offline.
  • Consider migrating to MQTT Sparkplug B for structured data while maintaining Modbus at the edge.

Understanding Modbus frames takes the guesswork out of commissioning and keeps data pipelines flowing smoothly.
