Modbus RTU & TCP: The Definitive Industrial Protocol Guide

If you work in industrial automation, Modbus is your daily bread. It is the “Esperanto” of machines: old, simple, and supported by absolutely everyone.

But that simplicity is deceptive. “It’s just Modbus” is the famous phrase before losing 3 days fighting with a byte that is backwards. This guide covers what the manuals don’t tell you.

1. The Data Model: The 4 Tables

Modbus doesn’t know what a “temperature” or a “velocity” is. It only sees 4 distinct data tables. Understanding this is 80% of the battle.

Trap #1: Many modern devices map EVERYTHING to Holding Registers (40001) for simplicity. But if you try to write to a register defined by the manufacturer as “Read Only”, you will get an Exception 02 (Illegal Data Address).

2. RTU vs TCP: More than just a different cable

The difference isn’t just RS485 vs Ethernet. The frame structure changes.

Modbus RTU (Serial)

Based on silence intervals.

• Slave ID (1 byte): Who you are talking to.
• PDU (Protocol Data Unit): Function + Data.
• CRC (2 bytes): Cyclic Redundancy Check. Critical. If a bit is corrupted by noise, the CRC fails and the slave ignores the message. It doesn’t respond “error”, it just stays silent.

Modbus TCP (Ethernet)

Wraps the PDU inside a TCP/IP packet.

• MBAP Header (7 bytes): Replaces the CRC.
  • Transaction ID: To match requests/responses (async).
  • Unit ID: Used when talking to a TCP->RTU Gateway. If talking directly to a PLC, it’s often ignored (0 or 255), but if you pass through a gateway, this byte is the final serial slave address.

3. The Endianness Hell (Byte Swap)

Modbus defines a register as 16 bits [High Byte, Low Byte]. Simple. But what happens with a 32-bit Float (e.g., 24.5 °C)? You need 2 registers.

There is no standard here. Every manufacturer sends bytes in whatever order they want:

1. Big-Endian (Standard): AB CD (Most common).
2. Little-Endian (Byte Swap): DC BA (Common in PC/x86).
3. Mid-Big Endian (Word Swap): CD AB (Common in old PLCs).
4. Mid-Little Endian: BA DC.

Pro Tip: If you read a value that should be 220.5 and you see 0.0045 or 1.5e32, you have an Endianness problem. Don’t try to “scale” it. Rotate the bytes.

4. Addressing: 0 vs 1

• PLC Documentation: Says “Register 40001”.
• The Wire (Protocol): Requests address 0.

The protocol is Zero-Based.

• 40001 in manual -> Address 0 on wire.
• 40100 in manual -> Address 99 on wire.

If your SCADA software (Ignition, Node-RED) asks for “Modbus Address”, sometimes they expect the 40001 format and do the subtraction themselves. Other low-level libraries (pymodbus) expect the raw 0. Always check if your driver uses “1-based” or “0-based” addressing.

Summary

Don’t underestimate Modbus. It is robust because it is simple, but it is fragile if you don’t respect its rules:

1. Verify if it’s Coil, Input, or Holding.
2. Align Endianness for Floats and Longs.
3. Subtract 1 from the address if using low-level libraries.
4. In TCP, the Unit ID matters if there are gateways.
